1.1.2 Product Development Support
The Z8 MCU product line is fully supported with a range of
cross assemblers, C compilers, ICEBOX emulators, single and
gang OTP/EPROM programmers, and software simulators.
PRODUCT
ROM/RAM
Z86C03
512/60
Z86E03
512/60
Z86C04
1K/124
Z86E04
1K/124
Z86C06
1K/124
Z86E06
1K/124
Z86C08
2K/124
Z86E08
2K/124
Z86C30
4K/236
Z86E30
4K/236
Z86C31
2K/124
Z86E31
2K/124
Z86C40
4K/236
Z86E40
4K/236
Note: Z86Cxx signify ROM devices; 86xx signify EPROM devices; F = fixed; P = programmable
The Z86CCP01ZEM kit comes with:
•
Z8 CCP Evaluation Board
Z8 CCP Power Cable
•
•
ZiLOG Developer's Studio (ZDS) CD-ROM , Including
1
Windows-Based
GUI Host Software
•
1999 ZiLOG Technical Library
Z8 CCP User's Manual
•
A Z8 CCP Emulator Accessory Kit (Z8CCP00ZAC) is also
available and provides an RS-232 cable and power cable along
with the 28- and 40- pin ZIF sockets and 28- and 40- pin target
connector cables required to emulate/program 28/40 pin devices.
1. Windows is a trademark of the Microsoft Corporation.
UM001601-0803
Table 1-1. ZiLOG General-Purpose Microcontroller Product Family
I/0
T/C
AN
14
1
2
14
1
2
14
2
2
14
2
2
14
2
2
14
2
2
14
2
2
14
2
2
24
2
2
24
2
2
24
2
2
24
2
2
32
2
2
32
2
2
The Z86CCP01ZEM low-cost Z8 CCP™ real-time emula-
tor/programmer kit was designed specifically to support all the
products outlined in Table 1-1.
INT
WDT
POR
IN
6
F
Y
6
F
Y
6
F
Y
6
F
Y
6
P
Y
6
P
Y
6
F
Y
6
F
Y
6
P
Y
6
P
Y
6
P
Y
6
P
Y
6
P
Y
6
P
Y
Z8 Microcontrollers
Z8 MCU Product Overview
V
RC
SPEED
BO
(MHz)
Y
Y
8
N
Y
8
Y
Y
8
N
Y
8
Y
Y
12
N
Y
12
Y
Y
12
N
Y
12
Y
Y
12
N
Y
12
Y
Y
8
N
Y
8
Y
Y
16
N
Y
16
PIN
COUNT
18
18
18
18
18
18
18
18
28
28
28
28
40/44
40/44
1-3
