Z8 Microcontrollers
Serial I/O
9.10 RECEIVE CHARACTER AVAILABLE AND OVERRUN (Continued)
Bit Control
SMR
/Interrupt
Control
IRQ
3
9-12
SPI Compare Register (SCOMP)
SPI Shift Register
SPI Receive Buffer (RxBUF)
SPI Control
Figure 9-15. SPI Logic
ZiLOG
SK
D0
Port
Control
DI
SS
SPI
Clock
TCLK
SCLK + n
UM001601-0803
