12.1 Z8 FUNCTIONAL SUMMARY

Z8 instructions can be divided functionally into the following
eight groups:
• Load
• Bit Manipulation
• Arithmetic
• Block Transfer
• Logical
• Rotate and Shift
• Program Control
• CPU Control
The following summary shows the instructions belonging to
each group and the number of operands required for each. The
source operand is src, the destination operand is dst, and a con-
dition code is cc.
Table 12-1. Load Instructions
Mnemonic Operands
CLR dst
LD dst, src
LDC dst, src
LDE dst, src
POP dst
PUSH src
