- Page 1 Z8ENCORE000ZCO ® Z8 Encore! Flash Microcontroller Development User Manual UM014605-0208 ® Copyright ©2008 by Zilog , Inc. All rights reserved. www.zilog.com...
-
Page 2: Revision History
Revision History Each instance in Revision History reflects a change to this document from its previous revision. For more details, refer to the corresponding pages and appropriate links in the table below. Date February 2008 July 2003 July 2003 March 2003 March 2003... -
Page 3: Table Of Contents
Z8 Encore! Table of Contents Introduction ..........1 Kit Contents . - Page 4 ® Z8 Encore! Flash Microcontroller Development Kit User Manual Pushbuttons ........29 Schematics .
-
Page 5: Introduction
Introduction Zilog’s Z8 Encore! line of Zilog microcontroller products. This board supports the Z8 Encore! and introduces Flash to the Z8 The Z8 Encore! Development Kit (Z8ENCORE000ZCO) allows you to become familiar with the hardware and software tools available with this product. -
Page 6: Software (On Cd-Rom)
Smart Cable Evaluation Board Figure 1. Z8 Encore! Software (on CD-ROM) The software components of Z8 Encore! development kit include: • Zilog Development Studio II (ZDS II)—Z8 Encore! Development Environment (IDE) with ANSI C-Compiler • Sample code • Device driver software •... -
Page 7: Documentation
Documentation The following documentation are included in the Z8 Encore! development kit: • Programmer’s Reference Sheet • Registration card • Z8 Encore! – ZDS II—IDE User Manual – eZ8 CPU User Manual – Product Specification – Product briefs – Application notes –... -
Page 8: System/Software Requirements
System/Software Requirements IBM PC (or compatible computer) with the following recommended configurations: Supported Host System Configuration The following system configurations are required on the host PC: • Microsoft Windows XP SP1/Windows 2000 SP3/Windows NT 4.0 SP6/Windows 98 SE • Pentium II/233 MHz processor or higher up to Pentium IV, 2.8 GHz •... -
Page 9: Installation
Installation This chapter describes the installation of hardware and software tools for the Z8 Encore! Evaluation Kit. Also describes setting up the evaluation board, substituting plug configurations of the universal 9 V DC power supply, and installing the ZDS II—IDE Z8 Encore! software. Setting up the Evaluation Board The PC communicates with the Z8 Encore! Flash MCU Evaluation board using the serial port of the PC. -
Page 10: Changing The Universal 9 V Dc Power Supply Plug Configurations
Serial Port 9 V Universal Power Supply Figure 2. Evaluation Board External Connections Changing the Universal 9 V DC Power Supply Plug Configurations Figure 3 displays the contents of the Universal Power Supply kit. Plug Configurations Figure 3. 9 V DC Universal Power Supply Components UM014605-0208 ®... - Page 11 The 9 V DC universal power supply features three different plug configu- rations, the power supply and a tool that aids in removing one plug con- figuration to insert another. Follow the steps below to substitute one plug configuration for another: 1.
-
Page 12: Installing The Zds Ii-Z8 Encore!® Software
Installing the ZDS II—Z8 Encore! Follow the steps below to install the software tools: 1. Load the ZDS II—Z8 Encore! Flash MCU CD into the CD-ROM drive of the host PC. The CD launches DemoShield automatically and provides a menu to install the product and documentation. Select INSTALL PRODUCTS followed by INSTALL ZDS II to display the Installation Wizard. -
Page 13: Getting Started
Getting Started Using ZDS II Follow the steps below to open an existing project: 1. Connect the Evaluation board to the host PC’s serial communications port using the Smart Cable. 2. Apply 9 V DC power to the Evaluation board. 3. -
Page 14: Z8 Encore! ® Evaluation Board
Z8 Encore! Z8 Encore! Introduction Z8 Encore! evaluation board (64 KB version) is an evaluation and proto- typing board for the Z8 Encore! you with a tool to evaluate features of Z8 Encore! family, and to develop an application before building the hardware. Features The features of the Z8 Encore! evaluation board include: •... -
Page 15: Block Diagram
Z8 Encore! Block Diagram The board consists of the following major blocks: • Z8 Encore! • Serial communication devices (SPI and I • Power and communication interfaces • LED array • Expansion Module interfaces • IrDA transceiver • Zilog Debug Interface (DBG) Figure 5. - Page 16 Z8 Encore! Figure 6 displays the Z8 Encore! Port A[0:7] Port B[0:7] Port C[0:7] Port D[0:7] Port E[0:7] Port F[0:7] Port G[0:7] Port H[0:3] ® Z8 Encore! IrDA IrDA RS-232 Console RS-485 RS485_1 RS-232 Modem Embedded Phone Line Modem RS-485 RS485_2 Figure 6.
-
Page 17: Mcu
Z8 Encore! The Z8 Encore! MCU family of products are the first in a line of Zilog MCU products based upon the new 8-bit eZ8 core CPU. The Flash in-circuit programming capability allows for faster development time and program changes in the field. The new eZ8 core CPU is upward compati- ble with existing Z8 Encore! makes it suitable for a variety of applications including motor control, security systems, home appliances, personal electronic devices,... -
Page 18: Led Array
Z8 Encore! • On-Chip Debugger • Voltage Brownout (VBO) Protection • Power-On Reset (POR) • 3.0 V–3.6 V operating voltage with 5 V-tolerant inputs • 0 °C–70 °C operating temperature For further information on the Z8 Encore! family of devices, refer to Z8 Encore! XP (PS0199). -
Page 19: Serial Communications Devices
Z8 Encore! Table 2. LED Cathode/Modem/Trigger Function/Port E Bit No Cathode Column 0 Cathode Column 1 Cathode Column 2 Cathode Column 3 Cathode Column 4 Note: Column 0 = Leftmost Column Table 3. LED Addressing Function/Port, Bit No Serial Communications Devices C Interface The Z8 Encore! is compatible with I PCA8550). -
Page 20: Spi Interface
Z8 Encore! advantage. The configuration register for Write operation and 0x9C device. For more details on programming this device, refer to PCA8550 Product Specification (www.semiconductors.philips.com). Table 4. I C Address for Configuration Register on the PCA8550 (U2) Device/Bit No 7 Value SPI Interface The SPI allows the Z8 Encore! to exchange data between other peripheral... -
Page 21: Power And Communication Interfaces
Z8 Encore! Power and Communication Interfaces The following are the power and communication interfaces: • 9 V DC power supply powers the board • Two RS-232 DB9 connectors and an RS-485 connector with two ports • Zilog IrDA transceiver is integrated onto the Z8 Encore! board Smart Cable The Z8 Encore! Smart Cable enables communication with the Host... - Page 22 Z8 Encore! Table 5. Header J6 Pin No Signal Name Function 9 V DC 9 V DC C Clock Evaluation Board C Data Evaluation Board Evaluation Board -MOD_DIS Modem Disable -CON_DIS Console Disable -MWAIT Port E, bit 0 -CS3 Note: Do not use pins marked Reserved when designing Expansion Modules. All the signals are driven directly by the MCU.
- Page 23 Z8 Encore! Table 5. Header J6 (Continued) Pin No Signal Name Function Port E, bit 7 Port A, bit 0 Port E, bit 6 Port A, bit1 Port E, bit 5 Port A, bit 2 Port E, bit 4 Port A, bit 3 Port E, bit 3 Port A, bit 4 Port E, bit 2...
- Page 24 Z8 Encore! Table 5. Header J6 (Continued) Pin No Signal Name Function Port D, bit 3 Port C, bit 3 Port D, bit 2 Port C, bit 2 Port D, bit 1 Port C, bit 0 Port D, bit 0 Port C, bit 1 Note: Do not use pins marked Reserved when designing Expansion Modules.
- Page 25 Z8 Encore! Table 6. Header J8 (Continued) Pin No Signal Name Function Port B, bit 4 Port B, bit 5 Port B, bit 6 Port B, bit 7 Port H, bit 0 Port H, bit 1 Port H, bit 2 Port H, bit 3 Port F, bit 0 Port F, bit 1...
- Page 26 Z8 Encore! Table 6. Header J8 (Continued) Pin No Signal Name Function Read Write -RESET Pushbutton reset INSTRD -BUSACK -BUSREQ -NMI Port G, bit 0 Port G, bit 1 Port G, bit 2 Port G, bit 3 Port G, bit 4 Port G, bit 5 Port G, bit 6 Port G, bit 7...
-
Page 27: Configuration Headers/Jumpers
Z8 Encore! Table 6. Header J8 (Continued) Pin No Signal Name Function -MEMRQ -IORQ Note: Do not use pins marked Reserved when designing Expansion Modules. All the signals are driven directly by the MCU. Configuration Headers/Jumpers Configuration headers/jumpers help to configure the board. lists the function of each header, and related headers, registers, or devices. - Page 28 Z8 Encore! Table 7. Configuration Headers and Jumpers (Continued) Header Table 8 through status, functions, and devices affected of selected jumpers. Table 8. J6.9–J6.11-Modem Enable/Disable Shunt Status Function Modem connector (P2) is disabled Modem connector (P2) is enabled Table 9. J6.12–J6.14-Console Enable/Disable Shunt Status Function...
- Page 29 Z8 Encore! Table 10. J7 External Vref Shunt Status Function External Vref is used for ADC Internal Vref is used for ADC Table 11. J9 Vref Function J9-1 Test point to external Vref J9-2 Table 12. J10 IrDA Enable/Disable Shunt Status Function IrDA enabled IrDA disabled...
- Page 30 Z8 Encore! Table 13. J11 SocketModem Power (3 V DC/5 V DC) Shunt Position Function IN (pins 1-2) 5.0 V DC is provided to power SocketModem OUT (pins 2-3) 3.3 V DC is provided to power SocketModem Table 14. J12–RS-485_1_Enable First Interface Shunt Position Function RS-485 disabled...
- Page 31 Z8 Encore! Table 17. J15–RT_2, Termination Resistors Enable, RS-485 Second Interface Shunt Position Function Second RS-485 interface termination resistors disabled Enables second RS-485 interface termination resistors UM014605-0208 ® Flash Microcontroller Development Kit Device Affected none none Z8 Encore!® Evaluation Board User Manual...
-
Page 32: Embedded Modem
® Z8 Encore! Flash Microcontroller Development Kit User Manual Embedded Modem Figure 7 displays the embedded modem location. Figure 7. Embedded Modem Placement The evaluation board provides for an embedded modem, the SF56D/SP SocketModem. The SocketModem is not part of the kit. Table 18 on page 29 lists ordering information for the modem. -
Page 33: Pushbuttons
Z8 Encore! Table 18. SocketModem Ordering Information Sales Order Number Part Number SC56H1 SC43-E310-001 SC56H1_L SC43-E320-001 SC336H1 SC34-E310-001 SC336H1_L SC34-E310-001 SC144H1 SC14-E310-001 SC144H1_L SC14-E310-001 Pushbuttons The Z8 Encore! buttons (see Figure 8. User-Configurable Pushbuttons UM014605-0208 ® Flash Microcontroller Development Kit Configuration V.90/56 kbps, serial interface, +5 V operation V.90/56 kbps, serial interface, +3.3 V operation... -
Page 34: Schematics
Schematics Figure 9 through Figure 13 display schematics for the Z8 Encore! Target Module and the Z8 Encore! Evaluation Board Z8F64 & C O N N EC TO R S D O N O T U SE J6_17 AN D J6_35 9V_DC 9VDC ID_2... - Page 35 CT1_0 CT1_1 CT1_2 CT1_3 CT1_4 AN1_0 0.1uF 74HCT374 AN1_1 AN1_2 AN1_3 AN1_4 AN1_5 0.1uF 74HCT374 AN1_6 AN2_0 AN2_1 AN2_2 AN2_3 AN2_4 AN2_5 AN2_6 0.1uF 74HCT374 74HCT374 SW PUSHBUTTON SW PUSHBUTTON SW PUSHBUTTON UM014605-0208 CT3_0 CT2_0 CT3_1 CT2_1 CT3_2 CT2_2 CT3_3 CT2_3 CT3_4 CT2_4...
- Page 36 PA5_TXD0 T1IN T1OUT T2IN T2OUT PA3_CTS0 R1OUT U20A PA4_RXD0 R2OUT -0_CON_DIS -1_CON_DIS SHDN 74LVC00/SO MAX3222 U17B 74LVC04/SO TXD1 PD5_TXD1 T1IN T1OUT DTR1 T2IN T2OUT PF0_DTR1 RTS1 PF1_RTS1 T3IN T3OUT -MOD_DIS FORCEOFF FORCEON INVALID R2OUTB PF4_RI1 PF2_DSR1 R1OUT R1IN R2OUT R2IN PD6_CTS1 R3OUT R3IN...
- Page 37 RS485_1_EN PA4_RXD0 PA5_TXD0 DS1487 PD4_RXD1 PF1_RTS1 PD5_TXD1 DS1487 RS485_2_EN UM014605-0208 0.1uF RT_1 0.1uF RT_2 ® Figure 12. Z8 Encore! Evaluation Board (96C0868-001 Rev.C) ® Z8 Encore! Flash Microcontroller Development Kit -0_CON_DIS U24C TC74LVT125 -DIS_IRDA U24B TC74LVT125 con8 -MOD_DIS U24D TC74LVT125 Title Schematic, Z8F Encore Evaluation Board Size...
- Page 38 ® Z8 Encore! Flash Microcontroller Development Kit User Manual ® Figure 13. Z8 Encore! Smart Cable UM014605-0208 Schematics...
-
Page 39: Index
Z8 Encore! Index addressing, LED 14 anode and cathode 14 anode assignments 14 array, LED 14 block diagram 12 blocks, evaluation board 11 C address for configuration register 16 cathode/modem assignments 15 communication devices, serial 15 configuration 4 headers 23 register, I2C 16 connectors, RS-232 and RS-485 17 console enable/disable 25... - Page 40 Z8 Encore! hardware 1 host system configuration 4 configuration register 16 I2C interface 15 infrared communication 16 installation 5 the ZDC II Z8 Encore! software 8 wizard screen shot 8 interface four-wire 16 I2C 15 SPI 16 IrDA enable/disable 26 transceiver 16 J11 VDC values 26 J6 signals, pins and functions 18...
- Page 41 Z8 Encore! shunt status 24 signals J6 17 J8 20 SocketModem 28 power 26 SocketModem ordering information 29 software 2 SPI interface 16 suggested host system configuration 4 system/software requirements 4 user-configurable pushbuttons 29 using ZDS 9 Vref 25 Z8 Encore! features 13 Z8 Encore! MCU 13 UM014605-0208...
-
Page 42: Customer Support
® Z8 Encore! Flash Microcontroller Development Kit User Manual Customer Support For answers to technical questions about the product, documentation, or any other issues with Zilog’s offerings, please visit Zilog’s Knowledge Base at http://www.zilog.com/kb. For any comments, detail technical questions, or reporting problems, please visit Zilog’s Technical Support at http://support.zilog.com. - Page 43 ® Z8 Encore! Flash Microcontroller Development Kit User Manual DO NOT USE IN LIFE SUPPORT Warning: LIFE SUPPORT POLICY ZILOG'S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL COUNSEL OF ZILOG CORPORATION.
