Z8 Microcontrollers
Interrupts
7.6 VECTORED PROCESSING (Continued)
7-10
Program Memory
XXFFH
PC HIGH Byte
FLAGS
000CH
0000H
Figure 7-12. Interrupt Vectoring
Interrupt
Service
Routine
Vector Selected
By Priority Logic
Interrupt
Vector Table
ZiLOG
UM001601-0803
