Replacing the processor

WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in
in After working inside your
www.dell.com/regulatory_compliance.
CAUTION: If either the processor or the heat sink is replaced, use the thermal grease provided in the kit to ensure
that thermal conductivity is achieved.
NOTE: A new processor ships with a thermal pad in the package. In some cases, the processor may ship with the
thermal pad attached to it.

Procedure

1 Place the processor into the processor cover.
2 Align the tabs on the processor cover with the processor.
3 Slide the processor cover into the processor slot.
4 Press the left-release lever and right-release lever on the processor cover to secure the tab.
5 Place the processor shield.
90
Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at
computer. After working inside your computer, follow the instructions
