Removing the front-bezel heat sensor cable

WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in
in After working inside your
www.dell.com/regulatory_compliance.

Prerequisites

1 Remove the stability
2 Remove the left and right side-panels. See
3 Remove the PCI fan.

Procedure

1 Disconnect the front-bezel heat sensor cable from the system board.
2 Remove the front-bezel heat sensor cable from the routing guides on the chassis.
3 Remove the two screws (M3x5.25) that secure the PCI fan holder to the chassis.
4 Slide and remove the PCI fan holder from the chassis.
80
Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at
foot.
"Removing the side
computer. After working inside your computer, follow the instructions
panels".
