Removing the battery case

WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in
in After working inside your
www.dell.com/regulatory_compliance.

Prerequisites

1 Remove the stability
2 Remove the right side-panel. See
3 Remove the battery.

Procedure

1 Lay the chassis on the left side.
2 Press the release tabs on the cable connector to disconnect the battery-case cable from the I/O board.
3 Remove the battery-case cable from the routing guides on the chassis.
4 Remove the two screws (#6-32x5.2) that secure the battery case to the chassis.
5 Lift the battery case off the chassis.
32
Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at
foot.
"Removing the side
computer. After working inside your computer, follow the instructions
panels".
