Technical overview

WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in
in After working inside your
www.dell.com/regulatory_compliance.

Inside view of your computer

To view the different components installed in your computer. See

Right view

Figure 1. Right view
1 I/O board (IO BRD)
3 drive-bay heat-sensor
5 AlienFX side-panel connector
7 3.5-inch drive bracket (HDD1)
9 3.5-inch drive bracket (HDD3)
Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at
computer. After working inside your computer, follow the instructions
"Left view" and
2 U.2 2.5–inch drive bracket (HDD3/HDD4)
4 U.2 2.5–inch drive bracket (HDD1/HDD2)
6 rear I/O accessibility lighting batteries
8 3.5-inch drive bracket (HDD2)
"Right view".
