Replacing the PCI fan

WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in
in After working inside your
www.dell.com/regulatory_compliance.

Procedure

1 Align the tabs on the PCI-fan with the slots on the chassis and slide the fan until it snaps into position.
2 Replace the screw (M3x5.25) that secure the PCI fan to the chassis.
3 Connect the PCI-fan cable to the connector on the system board.

Post-requisites

1 Replace the left and right side-panels. See
2 Replace the stability
Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at
"Replacing the side
foot.
computer. After working inside your computer, follow the instructions
panels".
79
