MICRO-EPSILON combiSENSOR 64x0 Instruction Manual page 67

Appendix| EtherCAT Documentation
Object 2060h: Controller settings
2060
Subindices
0
1
2
3
4
Object 2100h: Controller interface
2100
Subindices
0
1
3
4
5
6
7
combiSENSOR 6430
RECORD Controller Settings
VAR Number of entries
VAR Sample rate
VAR Averaging type
VAR Averaging number
VAR Trigger
RECORD Controller Interface
VAR Number of entries
VAR Ethernet/EtherCAT
VAR Ethernet Adress type
VAR Ethernet IPAddress
VAR Ethernet Subnet
VAR Ethernet Gateway
VAR Ethernet Dataport
4 Unsigned8
2083.3 Hz Enum
Off Enum
2 Enum
Off Enum
7 Unsigned8
EtherCAT Enum
Static Enum
169.254.168.150 Visible String
255.255.0.0 Visible String
169.254.168.1 Visible String
10001 Unsigned16
ro
ro
rw
rw
rw
rw
ro
ro
rw
rw
rw
rw
rw
rw
Page 67
