Ethernet Interface
6.5.4
This menu item determines the trigger behavior. The triggering is released by an external electrical signal, see
Chap.
If the trigger mode is turned off, the combiSENSOR 64x0 will send the measuring values without interruption
and with the adjusted data rate.

Trigger mode

6.5.5

Data Rate

6.5.6
Average type
It is recommended, to use averaging for statical measuring or slowly changing measuring values. An avera-
ging reduces noise or suppresses distortions in measuring values.
combiSENSOR 64x0
Trigger Mode
4.6.2 or by the command $ GMD, see Chap. 6.4.3.
Rising edge
High level
Gate rising edge
Off
Data Rate
2.6 / 5.21 / 10.42 / 15.63 / 26.04 / 31.25 / 52.08 / 62.5 /
104.2 / 520.83 / 1041.67 / 2083.33 / 3906.25 Sa/s

Filter, Averaging

Off
Moving
Arithmetic
Median
Dynamic noise rejection
A measuring value is output per edge.
Level triggering. Measuring value output, as long as the level is active.
Starts resp. stops the measuring value output alternatively.
Controller sends measuring values continuously.
Value
Value range 2 / 3
Value
/ 4 / 5 / 6 / 7 / 8
Value
Instructs the sensor about the
frequency, with which data are
output via the Ethernet interface.
Designation of averaging type.
Averaging number indicates,
about how many current measu-
ring values should be averaged
in the controller, before a new
measuring value is output.
