Ethernet Interface
Thickness
measurement
Calculate dielec-
tric constant
combiSENSOR 64x0
Dielectric constant
r
Offset
Max. working distance
sensor
Clear
Zero thickness
Submit
Difference signal without
target
Difference signal with
target
Max. working distance
r
sensor
Thickness object
Dielectric constant
r
Calculate
Dielectric constant of the target used. When the di-
Value electric constant is calculated, the controller replaces
the original value.
Standard value: 0. Adds a constant [µm] to the thick-
Value
ness value.
Working distance sensor [µm], value range: 5000 µm
Value
or 10000 µm.
This button deletes the thickness measurement func-
tion, channel 1 outputs the difference = Eddy - Capa.
This button sets the value of the offset in such a way
that the thickness signal is 0 µm.
Clicking onto this button permanently stores the
values in the controller. Subsequently, the controller
calculates based on the new values.
Step 1: Remove the measurement object from the
Value measuring gap, click onto the button Set current
position.
Step 2: Move the measurement object into the
Value measuring gap, click onto the button Set current
position.
Step 3: Enter the value [µm] for the maximum working
Value
distance. Value range: 5000 µm or 10000 µm.
Step 4: Enter the thickness value [µm] of the master
Value
target.
Value Calculated dielectric constant
Clicking onto the button starts the calculation of the
dielectric constant .
r
