Appendix| EtherCAT Documentation
Object 2010h: Controller information
2010
Subindices
0
1
2
3
4
5
Object 2020h: Channel information
2020
Subindices
0
1
2
5
7
8
The structure of objects 2021h to 2023h corresponds to the object 2020h.
combiSENSOR 6430
RECORD Controller info
VAR Number of entries
VAR Name
VAR Serial No
VAR Article No
VAR Option No
VAR Firmware version
RECORD Channel 1 info
VAR Number of entries
VAR Name
VAR Serial No
VAR Status
VAR Range
VAR Unit
5 Unsigned8
DT6230 Visible String
xxxxxxxx Unsigned32
xxxxxxx Unsigned32
xxx Unsigned32
xxx Visible String
5 Unsigned8
DL64x0 Visible String
xxxxxxxx Unsigned32
Active Enum
100 Unsigned32
µm Enum
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
rw
ro
