Ethernet Interface
6.4.9
Reads all settings at once.
The individual parameters are separated by a semicolon. The structure of the respective responses corre-
sponds to those of the individual requests.
Command
Response
6.4.10
Requesting the current software version.
Command
Response
6.4.11
Changes the IP settings of the controller.
Command
Example
Response
Index
Request
settings
Command
Response
combiSENSOR 64x0

Status (STS)

STS
$STS<CR>
$STSSTIn;AVTn;AVNn;CHS...;TRG.OK<CRLF>

Version (VER)

VER
$VER<CR>
$VERDT6400;V1.2a;8010079<CRLF>

Ethernet Settings (IPS)

IPS
$IPSm,<IPAddress>,<SubnetAddress,<GatewayAddress>
<CR>
$IPS0,169.254.168.150,255.255.0.0,169.254.168.1<CR>
$IPSm,<IPAddress>,<SubnetAddress>,<GatewayAddress>OK<CRLF>
m = 0: static IP address
m = 1: activates DHCP*
* If DHCP is active, no IP subnet- and gateway address has to be transmitted.
$IPS?
$IPS? m,<IPAddress>,<SubnetAddress>,<GatewayAddress>OK<CRLF>
Page 41
