SmartFusion2 Dual-Axis Motor Control Starter Kit

2 SmartFusion2 Dual-Axis Motor Control
Starter Kit
2.1

Introduction

The SmartFusion
time-saving and proven motor control reference designs. The kit is supplied with the hardware IP blocks
and software. A fully integrated solution along with a powerful and easy to use GUI that enables
designers to quickly prototype the design is also provided. The kit helps designers in customizing and
developing dual-axis motor control solution on the SmartFusion2 device for a specific application and
reduces time-to-market. This document provides details about the hardware setup and connections for
running the demo design.
2.2

Design Requirements

The following table lists the hardware and software requirements for this demo design.
Table 1 • Design Requirements
Design Requirements
Hardware
SmartFusion2 Dual-Axis Motor Control Starter Kit
board (SF2-MC-STARTER-KIT-SA) with SOM
FlashPro4 programmer or later
Brush less DC (BLDC) motor (QBL4208-41-04-006) One
Stepper motor (QSH4218-35-10-027)
USB A to mini-B USB cable
Power adapter (ETSA240270UDC-P5P-SZ)
Operating System
Software
®
Libero System-on-Chip (SoC)
Microsemi Motor Control GUI
USB drivers for GUI
FlashPro programming software
2.3

Demo Design

The programming files are available for download at:
http://soc.microsemi.com/download/rsc/?f=m2s_dg0598_liberov11p8sp2_pf
The programming files include:
• Programming File
• readme.txt
®
2 Dual-Axis Motor Control Starter Kit gives designers a starting point to evaluate
DG0598 Demo Guide Revision 7.0
Description
–
–
One
–
24 V
Any 64-bit or 32-bit Windows 7 or Later
Operating System
v11.8 SP2
v5.8
–
v11.8 SP2
2
