Microsemi SmartFusion2 Quick Start Card

SmartFusion2 SoC FPGA Evaluation Kit Quickstart
Card
Kit Contents – M2S-EVAL-KIT
Quantity
1 SmartFusion2 SoC FPGA 25K LE M2S025T-1FGG484
1 12 V/ 2 A Wall-Mounted Power Supply
1 FlashPro4 JTAG programmer
1 USB 2.0 A-male to mini-B Y-cable for UART/power interface (up to 1 A) to PC
1 Quickstart Guide
1 Libero SoC Gold Software License
1 PCIe Control Plane Demo Design
Note: The M2S-EVAL-KIT is RoHS compliant.

Overview

®
Microsemi's SmartFusion 2 SoC FPGA Evaluation Kit is the lowest cost FPGA platform for developing cost-optimized
FPGA designs using Microsemi's SmartFusion2 System-on-Chip (SoC) FPGAs, which integrate inherently reliable
flash-based FPGA fabric, a 166 MHz ARM
blocks, SRAM, eNVM, and industry-required high-performance communication interfaces, all on a single chip. The
SmartFusion2 SoC FPGA Evaluation Kit makes it easy to develop transceiver I/O-based FPGA designs to build PCI
®
Express and Gigabit Ethernet-based systems. The board is also small form-factor PCIe compliant, which will allow
quick prototyping and evaluation using any desktop PC or laptop with a PCIe
The kit enables you to:
• Develop and test PCI Express Gen2 x1 lane designs
• Test signal quality of the FPGA transceiver using the full-duplex SERDES SMA Pairs
• Measure the low power consumption of the SmartFusion2 SoC FPGA
• Quickly create a working PCIe link with the included PCIe Control Plane Demo
The board includes an RJ45 interface to 10/100/1000 Ethernet, 512 MB of LPDDR, 64 MB SPI Flash, and USB-UART
2
connections, as well as I C, SPI, and GPIO headers. The kit includes a 12 V power supply but can also be powered through
the PCIe edge connector. Also included is a free Gold License for the Libero
development and to utilize the reference designs made available with the kit. In addition, a FlashPro4 JTAG programmer is
included for programming and debugging.

Hardware Feature Overview

• SmartFusion2 SoC FPGA in the FGG484 package (M2S025T-1FGG484, 25K LE part)
• 64 MB SPI Flash memory
• 512 MB LPDDR
• PCI Express Gen2 x1 interface
• Four SMA connectors for testing of the full-duplex SERDES channel
• RJ45 interface for 10/100/1000 Ethernet
• JTAG/SPI programming interface
2
• Headers for I C, SPI, GPIOs
• Push-button switches and LEDs for demo purposes
• Current Measurement Test Points

Running the Demo

The SmartFusion2 SoC FPGA Evaluation Kit ships with the PCI Express Control Plane demo preloaded. For
instructions on running the demo and for more information, refer to the SmartFusion2 SoC FPGA Evaluation Kit PCIe
Control Plane Demo User's Guide.
January 2014
© 2014 Microsemi Corporation
Description
®
Cortex™-M3 processor, advanced security processing accelerators, DSP
®
slot.
®
SoC software toolset to enable FPGA
