Appendix: Connecting the Motor Terminals

4.1.1

Stepper Motor Connections

The stepper motor has four terminals. The motor terminals of the stepper motor must be connected to

the four pin plug, as shown in the following figure.

Figure 33 • Wiring Diagram for Stepper Motor Connectors

Stepper Motor

QSH 4218-35-10-027

Black – PHS 4

Green - W

Red - V

Blue - U

DG0598 Demo Guide Revision 7.0
