SINTERIT Lisa Pro User Manual page 13

PACKAGING
POWER
Average power consumption 1 [kW]
Maximum power consumption 1,8 [kW]
INDEPENDENT HEATING SYSTEM
Max. temperature in the chamber 210 [​
ADDITIONAL PRINTER FEATURES
Coupling installed in LISA PRO Pneumatic quick-coupling Male Plug Nipple DN7.2
Average Nitrogen consumption 8 [l/min] = 0,48 [m​
PRINTER PARAMETERS
High accuracy max. print volume FLEXA & TPE - 110 x 150 x 250 [mm] (4.3 x 5,9 x 9.8
Min. layer thickness 0,075 [mm] (0.003 [in])
Min. wall thickness XZ 0,4 [mm] (0.015 [in])
The layer height Z (min-max) 0,075-0,175 [mm] (0.003-0.007 [in])
12
Total weight 89,0 [kg] (198 [lbs])
Size of package 730 x 630 x 1040 [mm] (28.7 x 24.8 x 40.9 [in])
Package weight 150 [kg] (331 [lbs])
Package contains Sinterit LISA Printer + set of accessories + Manuals
Power supply 220-240 [V] AC, 50/60 [Hz], 7 [A]
(100-130 [V] AC, 50/60 [Hz], 15 [A])
Tape of laser Class 4, IR 5 [W]; λ =808 [nm]
Beam divergence θ = 10 [°]
Beam output CW (continuous wave)
Multi zone Heated piston, cylinder,FEED BED, PRINT BED
Nitrogen chamber Built-in
Size of Print Bed 150 x 200 x 260 [mm] (5.9 x 7.9 x 10.2 [in])
[in])
PA - 90 x 130 x 230 [mm] (3.5 x 5,12 x 9 [in])
XY accuracy from 0,05 [mm] (0.002 [in])
o​ o​
C] / 392 [​ F]
3​
/hour]
​
Sinterit Lisa PRO USER MANUAL
