Installation Procedures

The MKPs are mounted into a wall, furniture, or any other convenient location. Follow the
instructions appropriate to the mounting option you have selected.
ATTENTION:
Preparing the site and installing the mounting bracket (mud ring) or
wall box
Choose a location that allows cable runs without interference. Allow enough depth for both
the wall box and the cables. You may need to install the cables into the wall, furniture, or
conduits before installing the control panel.
The installation must conform to national and local electrical codes and to the equipment's
size requirements. A cutout template that shows the cutout requirement for the circuitry
enclosure on the rear of the control panel is provided in
page 45).
ATTENTION:
Extron recommends installation using a UL listed wall box (available from Extron) for most
mounting options, but you can use the included mounting brackets (mud rings) instead.
NOTES:
6 MKP 2000 • Installation
• The control panel must be installed into a UL approved electrical wall box.
• Le panneau de contrôle doit être installé dans un boîtier mural approuvé UL.
• Follow all national and local building and electrical codes that apply to the
installation site.
• Respectez tous les codes électriques et du bâtiment, nationaux et locaux, qui
s'appliquent au site de l'installation.
• The templates provided in this manual are not to scale. Use these diagrams only for
reference.
• Les modèles fournis dans ce manuel ne sont pas à l'échelle. Utilisez ces schémas
seulement comme une référence.
• Extron provides one mud ring with each control panel. However, you may choose
to use a wall box. Because the tolerances on electrical boxes are very loose, Extron
recommends that you measure the actual box that you plan to use before making
any precise cuts.
•
Extron fournit un cadre d'installation avec chaque panneau de contrôle. Cependant,
vous pouvez choisir d'utiliser un boîtier mural. Les limites des boîtiers électriques
étant très mal définies, Extron recommande que vous mesuriez le boîtier que vous
pensez utiliser avant toute découpe.
• Before using the mud rings, verify that the installation conforms to national and local
electrical codes.
• The electrical box must be at least 2.5 inches (7 cm) deep to accommodate the
MKP rear enclosure.
• To meet the UL listing requirements, the MKP must be installed in a wall box.
Reference Information (see
