8.
9.
After you have uploaded the firmware to the MKP, refresh the web page. The version
number of the newly uploaded firmware is displayed on the
in figure 35), and on the
Figure 35.
Updating the firmware using a direct computer-to-MKP connection
If you have no network access available, you can upgrade the MKP firmware via a direct
connection between your computer and the MKP. Your computer must have Microsoft
Windows® 2000, XP, or higher loaded.
NOTE: You can obtain the latest version of firmware only by downloading it from the
42 MKP 2000 • HTML Operation
Navigate to the folder where you saved the firmware upgrade file, and open the file. Its
name is displayed in the field below
page.
Upgrade
ATTENTION:
•
Valid firmware files must have the file extension .S19. A file with any other
extension is not a firmware upgrade for this device and could cause the device
to stop functioning.
• Les fichiers firmware valides doivent contenir l'extension fichier .S19. Un fichier
avec n'importe quelle autre extension n'est pas une mise à jour de firmware
pour cet appareil et l'appareil pourrait arrêter de fonctionner.
NOTE: The original factory-installed firmware is permanently available on the MKP. If
the attempted firmware upload fails for any reason, the MKP automatically reverts
to the factory-installed firmware.
On the Firmware Upgrade page, click the
The firmware upload to the MKP may take several minutes. While the firmware is being
uploaded, the button changes to
Upload
shows , then , and then the firmware version number.
UPL 777
ATTENTION:
• While the firmware is uploading, do not press any front panel buttons or submit
any selections on the web pages.
•
Pendant que le logiciel est en train d'être chargé, n'appuyez sur aucun des
boutons en face avant ou ne modifiez pas les pages web affichées.
When the LED display shows
Firmware Upgrade
Current Firmware Version on the System Status Page
Extron website. If the computer connected to your MKP has no network access, you
must download the firmware to a computer with network access, then copy it to your
computer hard disk.
Current Firmware Version
button to start the update process.
Upload
Uploading...
, the firmware upload is complete.
...
System Status
page.
x.xx on the
Firmware
, and the MKP LED display
page (outlined
