Reference
Information

Mounting the MKP 2000

This section provides procedures for mounting the MKP 2000.

Electrical Box Cutout

Any standard box that meets the local electrical codes can be used, but boxes from
different manufacturers may have different size openings. Extron recommends testing the
fit of the MKP inside the electrical box and then placing the box flush against the mounting
surface and tracing the cutout area.

Panel Mount Cutout Template

The drawing in
accommodate the keypad circuit board for mounting an MKP 2000 on a flat surface. This
type of installation can include a desk or podium, or a control panel or dashboard, where
the back is protected and does not require an electrical box.
figure 37 on the next page shows the dimensions for cutting a hole to
MKP 2000 • Reference Information 45
