MAC Address field
The Media Access Control (MAC) address is hardcoded in the MKP and cannot be
changed.
Firmware field
The
Firmware
MKP.
Model field
The
Model
Part Number field
The
Part Number
this field displays

Switcher Control Settings Section

This section contains switcher settings that can be configured via the MKP. After making all
desired changes to the fields in this section, click the
section to implement your changes. Click
restore the previous settings.
MKP Connection Priority settings
Select the radio button for the type of connection between the MKP and the switcher.
• Primary – RS-232 Connection to Switcher — The MKP directly controls the matrix
switcher via its Switch RS-232 port.
• Secondary – IP Connection to Primary MKP — The MKP controls the switcher
through another (primary) MKP Internet address.
IP Connection to Switcher — The MKP directly controls the switcher through the
•
Ethernet (IP) port.
Host Control Port settings
If Primary – RS-232 has been selected in the MKP Connection Priority section, select one of
the following radio buttons to specify how the Host RS-232 port will function:
MKP 2000 — Commands received on the Host RS-232 port are executed by the MKP.
•
• Pass Through — Commands received on the Host RS-232 port are forwarded to the
connected switcher via the Switch RS-232 port.
If either Secondary – IP Connection to Primary MKP or IP Connection to Switcher
was selected in the MKP Connection Priority section, the Host Control Port Settings
selections are grayed out and unavailable.
Switcher Size settings
The MKP cannot determine the matrix size of the switcher to which it is connected. You
must use the
default switcher size is 16 x 16.
NOTE: After you set the size of the connected switcher input/output matrix, if you
attempt to use the front panel to tie to an input or output that is outside the available
range for your MKP or your connected matrix switcher, the LED display shows
field displays the currently version of firmware that is currently loaded on your
field shows the name of your MKP model:
field contains the part number of your MKP model. For the MKP 2000,
.
60-682-00
drop boxes to specify the number of inputs and outputs. The
Switcher Size
.
MKP 2000
button at the bottom of the
Submit
if you want to reject all your changes and
Cancel
MKP 2000 • HTML Operation
.
