Features - Mircom TX3 Series Installation And Operation Manual

1.1.2 Elevator Restriction Units
The TX3-ER-8 or TX3-ER-8-A Elevator Restriction Units limit building
accessibility by granting visitor access only to the destination floor.
1.1.3 Other Controllers
Other Mircom controllers, such as the Elevator Restrictor Unit and the Card
Access controller, may be networked with the Lobby Control Unit. The network
options include a peer-to-peer RS-485 network, an ethernet TCP/IP network, or a
combination ethernet TCP/IP network with RS-485 subnetworks. See
Networking TX3 Panels on page 44 for more information.
Notes:
1.2

Features

Features of the TX3 series include:
•
•
•
•
•
•
•
•
•
•
•
•
•
10 (119) Telephone Access System Installation and Operation Manual
LT-969 Copyright January 2017
In order for a panel to connect to an ethernet TCP/IP network, it
must satisfy the following conditions.
• It must be IP capable. Panels that are IP capable are usually
denoted by a "-A" or "-B" at the end of their model names.
• If the panel is not a Touch Screen, it must have a TX3-IP IP
Module installed.
Stainless steel front panel
Universal Series enclosure with a built-in rain hood
Large scrolling 8 x 20 LCD display that eliminates the need for an external
directory
Back-lit 16 digit keypad with dedicated operational buttons for Page Up,
Page Down, Call and Info
Provisions for postal lock and camera
Multilingual Display and Voice Greeting (English, French-Canadian and
Spanish) that provides instructions on how to use the Lobby Control Unit
Concierge/Security Desk/Guard Phone capability
Card Access Interface
Supports both Auto Dialer (ADC) and NSL (no phone bill)
Ability to network panels together (peer-to-peer)
Hands free, full duplex communication
Flexible one to four digit resident dial codes
Dials up to 18 digit telephone numbers
Introduction
Version 3.7
