SYSTEM FEATURES

SYSTEM FEATURES
SCROLLING DIRECTORY FEATURES:
T SCROLLING DIRECTORY
T Programmable using the lobby panel's keypad
®
or IBM PC
T 15 Characters Resident/Tenant Name length.
T Up to 1000 programmable Telephone Numbers; up to 11 digits
with up to 10 Area Code prefixes.
T Up to 1000 4-digits programmable Keyless Entry Codes.
Main Door activation codes from 0000 to 4999
Auxiliary Door activation codes from 5000 to 9999
T 4 lines by 20 characters VFD (Vacuum Fluorescent Display)
COMMON FEATURES FOR BOTH SCROLLING AND NON-SCROLLING TEL. ACCESS SYSTEMS:
T Programmable Pulse(Rotary) or Tone(DTMF) dialling.
T User selectable door activation number.
Main Door relay:
Auxiliary Door relay: 0 to 9 (DTMF only)
T Programmable Master Code for security and programming access.
T One 11-digit telephone number for long distance call.
T Variable Dial Code length: 1,2,3, or 4 digits format.
T Single or Multiple Entrances capability.
T Door Override connection for fire alarm; doors will pulse open during emergency.
T Built-in Post Office Lock micro switch.
T Connection for "Lock Back" door contact to provide door timer cutoff to prevent "tailgating".
T Entrance Active Relay Contacts for use of camera activation.
T Programmable "Door Open" timer (99 seconds max.)
T Programmable "On Line or Conversation Time" timer (99 minutes max.).
T Nonvolatile memory (EEPROM), retains programmed information during power failure.
T Watch Dog Timer circuit to automatically reset the unit to eliminate system latch-up.
T Voice Mail Access capability -the required digits can be entered through the entry panel's keypad.
MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems
T Up to 1000 programmable Telephone Number; up to 11 digits
0 to 9 (DTMF) or 7,8,9,0 (Pulse)
NON-SCROLLING DIRECTORY FEATURES:
with up to 10 Area Code prefixes.
T Up to 1000 4-digits programmable Keyless Entry Codes.
Main Door activation codes from 0000 to 4999
Auxiliary Door activation codes from 5000 to 9999
TSUPERTWIST 2 lines by 16 characters backlit
extended temperature LCD display.
