SYSTEM FEATURES

SCROLLING DIRECTORY FEATURES:
SCROLLING DIRECTORY
Programmable using the lobby panel's keypad
®
or IBM PC
15 Characters Resident Name length.
Capacity for up to 1000 Suites or Telephone Lines.
1000 reprogrammable KEYLESS ENTRY codes
for Residents plus five (5) spares for use of
building management.
4 lines by 20 characters VFD (Vacuum Fluorescent Display)
COMMON FEATURES FOR BOTH SCROLLING AND NON-SCROLLING TEL. ACCESS SYSTEMS:
No SUBSCRIBER PHONE LINE FEE is required.
User programmable MASTER CODE for security
and programming access.
Capability of rotary "PULSE" or touch tone "DTMF" dialling.
VARIABLE RESIDENT CODE LENGTH, 1, 2, 3 or 4 digit.
SINGLE or MULTIPLE ENTRANCES capability.
DOOR OVERRIDE connection for fire alarm. Doors will
pulse open during emergency.
Built-in POST OFFICE LOCK micro switch.
Connection for "LOCK-BACK" door contact to lock door
as soon as it is open to prevent "tailgating" through.
MAIN ENTRANCE ACTIVE RELAY CONTACTS for use
of camera activation.
AUXILIARY RELAY CONTACTS for use of auxiliary
entrance or garage door.
User Definable Start Number for auto-programming
the Residents' access codes.
Programmable "DOOR OPEN" timer (99 seconds max.).
Programmable "ON LINE or CONVERSATION TIME"
timer (99 seconds max.).
Adjustable number of RING CYCLES.
Built-in CALL WAITING feature.
MUSIC-ON-HOLD input for music source (mono) such
as radio or tape deck.
NONVOLATILE MEMORY (EEPROM), retains programmed
information during power failure.
GUARD or CONCIERGE telephone connection. Use for
calling the Residents or Suites.
DEDICATED TELEPHONE LINE, allows to dial 2 telephone
numbers of up to 11 digits.
Stainless Steel or Painted Vein (textured) lobby panels
(Universal or Continental type enclosures).
Watch Dog Timer circuit to automatically reset the unit to
eliminate system latch-up.
Compact, small, and easy to install Decoder/Relay Cabinets
with LED indicator for each phone line. Ideal for installers
and troubleshooting.
MIRCOM TECHNOLOGIES LIMITED, 9500 Series: No Subscriber Line
NON-SCROLLING DIRECTORY FEATURES:
Capacity for up to 1000 Suites or Telephone Lines.
Programmable using the lobby panel's keypad
1000 reprogrammable KEYLESS ENTRY codes
for Residents plus five (5) spares for use of
building management.
SUPERTWIST 2 lines by 16 characters backlit
extended temperature LCD display.
