Telephone Access System Installation and Operation Manual
Version 3.7
LT-969
Copyright January 2017
Secure the Kiosk onto the base plate using the 8 of the 12 base plate bolts
in the holes shown in Figure 14.
Attach the Kiosk to the base plate
with bolts in these holes first
Figure 14
Attach the Kiosk to the base plate
Position the reinforcement bracket over the 6 studs on the inside of the
Kiosk, and screw the 6 nuts on to the studs as shown in Figure 7.
Secure the reinforcement bracket to the base plate using the remaining 4
base plate bolts in the remaining 4 holes in the base plate.
Fit the door to the Kiosk.
Enclosure Installation
35 (119)
- Quick Links:
- Tx3 Systems
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the TX3 Series and is the answer not in the manual?
Questions and answers
How can the caller ID altered to show New title when a call is received ?
To alter the caller ID to show a new title on the Mircom TX3 Series, you need to edit each message line:
1. Scroll to the message line (Line-2 or Line-3).
2. Press the 1 key 9 times to enter an asterisk (*) if needed.
3. Edit the message content as desired to change the displayed title.
4. Press the telephone (enter) key to accept the changes.
5. Press the info key to return to the previous menu.
This answer is automatically generated
