Multiple Lobby Control Units

Figure 20 shows a configuration of many Lobby Control Units to one phone line.
The phone can be either a dedicated phone line from the phone company or an
NSL phone line from the NSL Control Unit.
Line1
1 2 3
4 5 6
7 8 9
* 0 # i
Lobby
control
unit 1
Figure 20. Many Lobby Control Units to One Line
