Lobby Control Units 1, 2 and 3 can make simultaneous calls as long as a line is not
in use by another Lobby Control Unit. For example, if Lobby Control Unit 1 uses
line1, Lobby Control Unit 2 can use Line 2 and Lobby Control Unit 3 can use
line 3.
When Lobby Control Unit 1 is using line 1 and Lobby Control Unit 2 also wants
to use line1, which is busy, then a line busy message displays on Lobby Control
Unit 2.
Lobby
control
unit 1
RS-485 from
previous unit
Figure 19. Multiple Lobby Control Units to Multiple Lines
42 (119)
Telephone Access System Installation and Operation Manual
LT-969
Copyright January 2017
Lobby
control
unit 2
Line3
Line2
Line1
1 2 3
1 2 3
4 5 6
4 5 6
7 8 9
7 8 9
* 0 # i
* 0 # i
RS-485
bus
NSL
Control
Unit
Lobby
control
T/R
unit 3
1 2 3
4 5 6
7 8 9
* 0 # i
RS-485 to
next unit
TX3 System
NSL
Control
Unit
T/R
T/R
Telephone outlet
Central office line
Version 3.7
