Mircom TX3 Series Installation And Operation Manual page 25

4.
5.
6.
7.
8.
9.
10.
To surface mount the Universal enclosure
1.
2.
3.
4.
5.
6.
Note:
To install the Universal enclosure with the Flush Trim Ring to the
back wall
1.
2.
Telephone Access System Installation and Operation Manual
Version 3.7
LT-969 Copyright January 2017
Using the semi-flush trim ring as a template, insert the trim ring into the
wall cut out and mark the top mounting hole location as shown in Figure 1.
Ensure that at least one side is beside a wall stud.
Place the screw halfway into the wall into the marked hole location using
the supplied screw.
Hang the Trim Ring onto the top screw.
Screw the lower two screw at the bottom of the trim ring halfway into the
wall.
Tighten the two screws into place.
Insert the universal enclosure with the rain hood inside the trim ring.
Secure the universal enclosure into the trim ring using the supplied four
screws as shown in Figure 1.
Find a suitable location for the Universal enclosure over a wall stud.
Using the Universal enclosure as a template, mark the two side mounting
hole locations as indicated in Figure 1. Ensure that at least one side is over
a wall stud.
Remove the enclosure and place the screws halfway into the marked hole
location and wall stud using the supplied screws.
Place the Universal enclosure onto the two screws.
Screw the two side screws of the Universal enclosure halfway into the
wall.
Tighten all four screws into place.
The enclosure can also be mounted directly onto the drywall using
anchors.
Find a suitable location for the enclosure. Using the enclosure as a
template trace an opening in the wall for the cut out.
Cut an opening in the wall.
Enclosure Installation
25 (119)
