TX3-2000-8U, TX3-2000-8U-A and TX3-2000-8U-B: Electronic Scrolling
Directory Lobby Control Unit Kit
•
•
•
•
•
•
•
•
1.3.2 Universal Slim-Line Series
The Universal Slim-Line series enclosure houses the following models and can
be surface or semi-flush mounted:
TX3-200-4U-A and TX3-200-4U-B: Slim-Line Electronic Scrolling
Directory Lobby Control Unit Kit
•
•
•
•
•
•
•
TX3-1000-4U-A and TX3-1000-4U-B: Slim-Line Electronic Scrolling
Directory Lobby Control Unit Kit
•
•
•
•
•
Telephone Access System Installation and Operation Manual
Version 3.7
LT-969 Copyright January 2017
Eight-line by 20 character LCD display
Main controller board for 2000 residents
PS-4P Transformer
Universal Enclosure complete with Rain Hood and Light Assembly
Designed for outdoor applications
TX3-2000-8U-A and TX3-2000-8U-B are IP capable
Provision for card reader (sold separately) or postal lock (TX3-2000-8U-B
only)
Provision for TX3-CX-1NP Single Door Control Module, sold separately
(TX3-2000-8U-B only)
4 Line by 20 LCD character display
Main controller board for 200 residents
PS-4P Transformer
Slim-line Universal Enclosure complete with Rain Hood and Light
Assembly
IP capable
Provision for card reader (sold separately) or postal lock (TX3-200-4U-B
only)
Provision for TX3-CX-1NP Single Door Control Module, sold separately
(TX3-200-4U-B only)
4 Line by 20 LCD character display
Main controller board for 1000 residents
PS-4P Transformer
Slim-line Universal Enclosure complete with Rain Hood and Light
Assembly
IP capable
