5.2.2

Input indicator

Some newer J-Links such as the J-Link PRO come with additional input/output Indica-
tors. The input indicator is used to give the user some information about the status
of the target hardware.
5.2.2.1 Bi-color input indicator
Indicator status
GREEN
ORANGE
RED
Table 5.3: J-Link bi-color input indicator
5.2.3

Output indicator

Some newer J-Links such as the J-Link PRO come with additional input/output Indica-
tors. The output indicator is used to give the user some information about the emula-
tor-to-target connection.
5.2.3.1 Bi-color output indicator
Indicator status
OFF
GREEN
ORANGE
RED
Table 5.4: J-Link bi-color output indicator
J-Link / J-Trace (UM08001)
Target voltage could be measured. Target is connected.
Target voltage could be measured. RESET is pulled low
(active) on target side.
RESET is pulled low (active) on target side. If no target is
connected, reset will be also active on target side.
Target power supply via Pin 19 is not active.
Target power supply via Pin 19 is active.
Target power supply via Pin 19 is active. Emulator pulls
RESET low (active).
Emulator pulls RESET low (active).
© 2004-2009 SEGGER Microcontroller GmbH & Co. KG
Meaning
Meaning
77
