Segger J-Link User Manual page 7

Revision
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
J-Link / J-Trace (UM08001)
Date By
Subchapter 1.5.1: Added target supply voltage and
target supply current to specifications.
060914 OO
Subchapter 5.2.1: Pictures of ways to connect J-
Trace.
Subchapter 4.7 "Using DCC for memory reads"
060818 TQ
added.
Subchapter 5.2.2: Corrected JTAG+Trace connec-
060711 OO
tor pinout table.
Subchapter 4.1: Added ARM966E-S to List of sup-
060628 OO
ported ARM cores.
Subchapter 5.5.2.2 changed.
060607 SK
Subchapter 5.5.2.3 added.
ARM9 download speed updated.
Subchapter 8.2.1: Screenshot "Start sequence"
updated.
060526 SK
Subchapter 8.2.2 "ID sequence" removed.
Chapter "Support" and "FAQ" merged.
Various improvements
Chapter "Literature and references" added.
Chapter "Hardware":
Added common information trace signals.
060324 OO
Added timing diagram for trace.
Chapter "Designing the target board for trace"
added.
Chapter "Related Software": Added JLinkARM.dll.
060117 OO
Screenshots updated.
051208 OO Chapter Working with J-Link: Sketch added.
Chapter Working with J-Link: "Connecting multiple
J-Links to your PC" added.
Chapter Working with J-Link: "Multi core debug-
051118 OO
ging" added.
Chapter Background information: "J-Link firm-
ware" added.
051103 TQ Chapter Setup: "JTAG Speed" added.
Chapter Background information: "Flash program-
ming" added.
051025 OO
Chapter Setup: "Scan chain configuration" added.
Some smaller changes.
051021 TQ Performance values updated.
051011 TQ Chapter "Working with J-Link" added.
050818 TW Initial version.
Explanation
© 2004-2009 SEGGER Microcontroller GmbH & Co. KG
7
