8.4.1.2 Connecting the isolator to target and emulator
The Emulator side of the Isolator is plugged directly into the Emulator. The target
side is connected to the target via a 20-pin flat cable. For more information about J-
Link JTAG isolator, please refer to UM08010 .
J-Link
J-Link
8.4.2

JTAG 14 pin adapter

An adapter is available to use J-Link / J-Trace with targets using this 14 pin 0.1" mat-
ing JTAG connector.
The following table shows the mapping between the 14 pin adapter and the standard
20 pin JTAG interface.
PIN
1
VTref
2
GND
3
nTRST
4
GND
5
TDI
6
GND
7
TMS
8
GND
9
TCK
10
GND
Table 8.10: Mapping between the JTAG 14 pin adapter and 20 pin JTAG interface
J-Link / J-Trace (UM08001)
Isolator
Flat cable
Signal
1
GND
3
GND
5
GND
7
GND
9
GND
© 2004-2009 SEGGER Microcontroller GmbH & Co. KG
Flat cable
Isolator
Target
Pin no. on 20 pin JTAG
161
Target
CPU
CPU
