J-Trace for Cortex-M3

J-Trace for Cortex-M3 is a JTAG/SWD emulator designed for
Cortex-M3 cores which includes trace (ETM) support. J-Trace for
Cortex-M3 can also be used as a J-Link and it also supports
ARM7/9 cores. Tracing on ARM7/9 targets is not supported.
1.1.8.1 Additional features
• Has all the J-Link functionality
• Supports tracing on Cortex-M3 targets
1.1.8.2 Download speed
The following table lists performance values (Kbytes/s) for writ-
ing to memory (RAM):
J-Trace Rev. 1
Table 1.6: Download speed differences between hardware revisions
The actual speed depends on various factors, such as JTAG, clock speed, host CPU
core etc.
J-Link / J-Trace (UM08001)
CHAPTER 1
Hardware Cortex-M3 via SWD
190 Kbytes/s (12MHz SWD)
