Datamax ?-class series Maintenance Manual page 91

D. Printer Assembly 2 of 3 (53-2153-01)
ITEM NUMBER PART NUMBER
1
2
14
15
26
32
41
43
45
48
12-3005-01 CENTERPLATE
15-2763-01 MEDIA SUPPLY ASSY
24-2613-01 ASSY-SENSOR
12-3006-01 SHAFT GUIDE
10-2913-01 FOOT STICK-ON
51-2358-00 CCA FRONT PANEL M-CLASS
10-2903-02 SCREW TRILOBULAR M4 PHILIPS HEAD 8
10-2903-04 SCREW TRILOBULAR M4 PHILIPS HEAD 12
17-3040-01 SPRING HEAD LIFT FRONT
16-2946-01 GROMMET, PRINT HEAD HARNESS
M-4206 Printer Assemblies
DESCRIPTION
5-9
