Removal and Replacement
4.8 Platen Rollers
Removal:
1
Turn 'Off' and unplug the printer.
2. Remove the side covers (see Section 8.0).
3. Remove the front cover (see Section 8.1).
4. Remove the Front Fascia, Thumbscrew, and Tearplate.
Tearplate
Thumbscrew
Front Fascia
4-19
