Datamax ?-class series Maintenance Manual page 139

A. Thermal Transfer (CSI: 78-2483-01; CSO: 78-2483-02)
ITEM NUMBER PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
20
Direct Thermal (78-2492-01)
ITEM NUMBER PART NUMBER
1
2
12-3002-01 HOUSING SUPPLY/TAKE-UP CSI
12-3002-02 HOUSING SUPPLY/TAKE-UP CSO
12-3006-01 SHAFT GUIDE
15-2768-11 SUPPLY ASSY RIBBON CSI
15-2768-12 SUPPLY ASSY RIBBON CSO
15-2776-21 CLUTCH ASSY RIBBON
17-3028-01 BEARING FLANGED 440C 3/8 X 7/8
10-0563-01 E-RING 3/8 TRUARC 5133-37
17-2869-01 WASHER FLAT NYLON
10-2113-13 WASHER FLT ROUND STEEL METRIC
10-2903-04 SCREW TRILOBULAR M4 PHILIPS HEAD 12
15-2840-01 ASSY HUB RIBBON REWIND
13-2409-01 DISK FRICTION .125 THICK
15-2841-01 ASSY THERMAL TRANSFER CSI
15-2841-02 ASSY THERMAL TRANSFER CSO
12-3264-01 COVER-RIBBON ASSY
10-2903-04 SCREW TRILOBULAR M4 PHILIPS HEAD 12
Option Assemblies
DESCRIPTION
DESCRIPTION
5-57
