Datamax ?-class series Maintenance Manual page 141

B. Internal Rewind (78-2484-01)
ITEM NUMBER PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
20
No Internal Rewind (78-2303-01)
ITEM NUMBER PART NUMBER
1
2
12-2925-01 HOUSING MEDIA TAKEUP
15-2840-01 ASSY HUB RIBBON REWIND
15-2802-41 CLUTCH ASSEMBLY MEDIA
17-3028-01 BEARING FLANGED 440C 3/8 X 7/8
17-2860-01 GEAR SPUR DELRIN 24TEETH
12-2905-01 POST IDLER
10-2903-06 SCREW TRILOBULAR M4 PHILIPS HEAD 25
10-0563-01 E-RING 3/8 TRUARC 5133-37
13-2409-01 DISK FRICTION .125 THICK
11-5613-01 RETAINER MEDIA
16-2931-01 BRACKET REWIND NONMETALLIC
15-2842-01 ASSY LABEL REWIND
12-2941-01 COVER-TAKE-UP ASSY
10-2903-04 SCREW TRILOBULAR M4 PHILIPS HEAD 12
Option Assemblies
DESCRIPTION
DESCRIPTION
5-59
