Datamax ?-class series Maintenance Manual page 129

E. Printer Assembly 3 of 3 (53-2153-03)
ITEM NUMBER PART NUMBER
21
22
23
24
25
26
27
33
34
35
36
40
41
43
44
24-2612-02 ASSEMBLY STEPPER MOTOR
17-3009-01 ISOLATOR VIBRATION
17-2810-01 GEAR SPUR DELRIN 24 PITCH 48 TEETH
17-3002-01 GEAR-IDLER 24 PITCH 36 TOOTH
12-2905-01 POST IDLER
10-2913-01 FOOT STICK-ON
10-0526-01 WASHER #8 SPLIT LOCK
11-5277-01 PLATE NUT
44-2060-01 ASSY FERRITE
17-3015-01 FASTENER TINNERMAN TWIN PUSH-ON
51-2357-00 CCA PWR. SUP. M-CLASS
10-2903-01 SCREW TRILOBULAR M4 PHILIPS HEAD 6
10-2903-02 SCREW TRILOBULAR M4 PHILIPS HEAD 8
10-2903-04 SCREW TRILOBULAR M4 PHILIPS HEAD 12
10-2903-06 SCREW TRILOBULAR M4 PHILIPS HEAD 25
M-4306 Printer Assemblies
DESCRIPTION
5-47
