Datamax ?-class series Maintenance Manual page 125

C. Printer Assembly 1 of 3 (53-2153-03)
ITEM NUMBER PART NUMBER
3
4
5
6
7
8
9
10
11
12
13
16
17
19
20
30
37
41
43
47
15-2850-01 ASSY-PRINTHEAD MOUNT
12-3165-01 PIN PRINTHEAD PIVOT
12-3157-01 BLOCK PLATTEN/PRINTHEAD PIVOT
12-3160-01 RETAINER LEFT
12-3161-01 RETAINER BEARING
12-3279-01 LEVER PRINT HEAD CAM LIFT
15-3000-01 ASSY M3 X 8 THUMB SCREW
17-3039-01 SPRING HEAD LIFT REAR
16-2965-01 SPACER .875 DIA
17-2858-01 SCREW HOLLOW KNURLED M4 X10
11-5344-01 TEAR BAR
16-2860-01 GUIDE-MEDIA
10-2904-01 WASHER FLAT NYLON .50 OD X .281 ID
10-2113-13 WASHER FLT ROUND STEEL METRIC
15-2847-03 ASSY-PLATEN UPPER 300 DPI
32-2521-01 CABLE ASSEMBLY OPTIONS CONTROL
20-2225-01 PRINTHEAD 300DPI 4.5"
10-2903-02 SCREW TRILOBULAR M4 PHILIPS HEAD 8
10-2903-04 SCREW TRILOBULAR M4 PHILIPS HEAD 12
19-2030-01 GREASE SILCONE
M-4306 Printer Assemblies
DESCRIPTION
5-43
