Datamax ?-class series Maintenance Manual page 143

C. Peel and Present (78-2482-01 & 78-2482-02)
ITEM NUMBER PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
30
40
12-3168-01 MOUNT-PEEL MECH
12-3275-01 COVER-PEEL MECH
16-2923-01 LATCH-PEEL MECHANISM
16-2877-01 COVER PRESENT SENSOR
16-2938-01 COVER WIRE PEEL MECHANISM
16-2869-01 MOUNT-PINCH ROLLER
16-2930-01 COVER-PEEL MECH BACK
16-2349-01 ROLLER - CLAMP
16-2349-02 ROLLER- CLAMP
16-2838-01 ROLLER-PEEL UPPER
12-3173-01 SHAFT-PEEL UPPER
13-0002-01 TYWRAP 4"
12-3202-01 SHAFT-PINCH ROLLER
10-2903-02 SCREW TRILOBULAR M4 PHILIPS HEAD "8
10-3021-02 E-RING. 1/8 CRES
10-3072-01 PIN DOWEL 3/32OD X 1.5LG
10-3058-01 PIN DOWEL .094 DIA X 1.188 LONG SST
17-2997-01 SPRING COMPRESSION .016 WIRE .240 O
17-2314-06 SPRING COMPRESSION LC-026B-9MW
51-2366-01 CCA PEEL&PRESENT SENSOR M-CLASS
10-3081-01 SCREW CAPTIVE FLUSH MOUNT M4
15-2847-02 ASSY- PLATEN LOWER 203 DPI
15-2847-04 ASSY- PLATEN LOWER 300 DPI
15-2945-01 ASSY-PEEL MECH
15-2945-02 ASSY-PEEL MECH, TEAR-UP
