Removal and Replacement
Installation:
1. Position the Drive Motor in the printer and secure using the two previously removed Screws and
Lock Washers.
2. Connect the Drive Motor Cable to its appropriate connector on the Power Supply PCB.
3. Re-install the Screw and Inner Bearing Plate.
4. Re-install the Tearplate, Thumbscrew, and Front Fascia.
5. Re-install the front cover (see Section 4.1).
6. Re-install the side covers (see Section 4.0).
4-18
