Icom IC-PCR1500 Instruction Manual page 75

16
SPECIFICATIONS AND OPTIONS
I Specifications
D D GENERAL
• Frequency coverage
U.S.A
France
Other than above
*Guaranteed: 0.495–3000.000 MHz range only
• Type of emission
• Number of memory channels
• Frequency resolution
• Operating temperature range
• Frequency stability
• Power supply requirement
• Current drain
(at 12.0 V DC: approx.)
• Antenna connector
• Dimensions
(proj. not included)
• Weight
(approx.)
73
: 851.000–866.9999
896.000–1299.9999
1300.000–1810.9999
1852.000–1867.9999
1897.000–2811.9999
2853.000–2868.9999
2898.000–3299.9999
: 50.200–51.2000
87.500–108.000
144.000–146.000
430.000–440.000
1240.000–1300.000
: 0.010–3299.9999
: FM, AM, WFM, USB, LSB, CW
: 1050 (incl. 50 scan edges )
: 1 Hz, 10 Hz, 20 Hz, 50 Hz, 100 Hz,
500 Hz, 1 kHz, 2.5 kHz, 5 kHz, 6.25 kHz,
8.33 kHz, 9 kHz, 10 kHz, 12.5 kHz,
15 kHz, 20 kHz, 25 kHz, 30 kHz, 50 kHz,
100 kHz, 125 kHz, 150 kHz, 200 kHz,
500 kHz, 1 MHz, 10 MHz
: –10°C to +60°C; +14˚F to +140˚F
: ±3 ppm
(–10°C to +60°C)
: 12.0 V DC ±15%
: standby 0.65 A (typical)
max. audio 1.2 A
(50 Ω)
: BNC
: 146(W) × 41(H) × 206(D) mm
5 3 ⁄ (W)×1 5 ⁄ (H)×8 1 ⁄ (D) in
4 8 8
: 1.2 kg; 2 lb 10 oz
D D RECEIVER
(MHz) • Receive system
• Intermediate frequencies
• Sensitivity:
FM (1 kHz/3.5 kHz Dev.; 12 dB SINAD)
28.000–29.999 MHz
30.000–49.999 MHz
50.000–239.999 MHz
240.000–279.999 MHz
280.000–299.999 MHz
300.000–699.999 MHz
700.000–1299.999 MHz
1300.000–2299.999 MHz
2300.000–3000.000 MHz
WFM (1 kHz/52.5 kHz Dev.; 12 dB SINAD)
50.000–699.999 MHz
700.000–1299.999 MHz
1300.000–2299.999 MHz
2300.000–3000.000 MHz
AM
(1 kHz/30% MOD.; 10 dB S/N)
0.495–1.799 MHz
1.800–14.999 MHz
15.000–49.999 MHz
50.000–299.999 MHz
300.000–699.999 MHz
700.000–1299.999 MHz
: Triple-conversion superheterodyne and
down converter
: 1st: 266.700 MHz, 2nd: 10.700 MHz
3rd: 450 kHz
(except for WFM mode)
: Less than 0.63 µV
: Less than 0.63 µV
: Less than 0.5 µV
: Less than 0.5 µV
: Less than 0.5 µV
: Less than 0.5 µV
: Less than 0.63 µV
: Less than 5.6 µV
: Less than 18 µV
: Less than 1.4 µV
: Less than 1.8 µV
: Less than 18 µV
: Less than 56 µV
: Less than 25 µV
: Less than 2.5 µV
: Less than 2.5 µV
: Less than 2 µV
: Less than 2 µV
: Less than 2.5 µV
