Icom IC-PCR1500 Instruction Manual page 69

I Operation
The computer can be remotely controlled using DTMF codes
in FM mode. When receiving a programmed DTMF code, the
IC-PCR1500 displays a message, activates a program/screen
saver or plays a Windows' sound file.
q Select FM mode.
w Click "
" on the tool bar to call up the [DTMF Remote
Commander] screen if it is not displayed.
eClick [ON/OFF] on the DTMF Remote Commander screen
to toggle the DTMF decoder circuit ON and OFF (the LED
lights when the function is ON).
rClick the [REMOTE] button to toggle the DTMF remote
function ON and OFF (the LED lights when the function is
ON).
NOTE: When receiving a signal including a DTMF code,
the received code is displayed in the DTMF indicator win-
dow. Up to 24 digits of the latest received DTMF code are
displayed.
DTMF OPERATION
D Setting the DTMF receive code
q Click "
" on the tool bar to call up the [DTMF Remote
Commander] screen if it is not displayed.
w Click [SET] to call up the receive code setting screen.
e Click the desired tab from [1] to [5] for the receive code
setting.
r Enter the desired key code in the [Receive CODE] field
using the keyboard.
• 0 to 9, A, B, C, D, E (∗) and F (#) can be used.
t Select the desired action from "Display Message", "Action
Execute File" or "Play.WAV File" when the received code is
matched to the [Receive CODE] setting.
(a) 'Display Message'
To display a entered message in the text box.
(b) 'Action Execute File'
To execute a file, enter the file name, including full path
name, or select a desired file after pushing the [..] but-
ton.
(c) 'Play.WAV File'
To play a file, enter the file name, including full path
name, or select a desired file after pushing the [..] but-
ton.
yClick the close button ([X]) to close the DTMF Remote
Commander screen.
