Icom IC-PCR1500 Instruction Manual page 28

4
PANEL DESCRIPTION
I Multi-function receiver screen (Continued)
$1 VOICE SCAN CONTROL BUTTON [VSC] (p. ??)
Click to turn the VSC (Voice Scan Control) function ON or
OFF.
• "VSC" appears when the VSC function is turned ON.
$2 DTCS SETTING BUTTON [DTCS] (p. ??)
➥ Click to display the DTCS code setting screen, then click
[Z] to select the desired code.
➥ Click the polarity radio button to select the polarity from
Normal or Reverse.
• Available only when FM mode is selected.
• "DTCS" appears when the DTCS code and polarity are set.
• Click again to cancel the DTCS setting.
$3 CTCSS SETTING BUTTON [TSQL] (p. ??)
Click to display the tone squelch frequency setting screen,
then click [Z] to select the desired frequency.
• Available only when FM mode is selected.
• "CTCSS" appears when the tone squelch frequency is set.
• Click again to cancel the CTCSS setting.
$4 ENTER KEY [ENT]
Click to enter the frequency when the desired receive
frequency is input via the 10 keypad.
$5 MEMORY CHANNEL KEY [Mch]
Click to call the memory channel when the desired channel
number is input via the 10 keypad.
$6 TENKEY— DECIMAL BUTTON [.]
Click to set the MHz digit when inputting a frequency via
the 10 keypad.
25
$7 TENKEY— CLEAR BUTTON [CE]
Click to clear the mistake while inputting a receive
frequency or memory channel number via the 10 keypad.
$8 TENKEY— NUMERAL BUTTONS [1] to [0]
The numeral buttons can be used for several functions as
below:
• Direct receive frequency input.
• Memory channel input.
