Icom IC-PCR1500 Instruction Manual page 52

8
SCAN OPERATION
I Scan types
PROGRAMMED SCAN
(p. ??)
Scan edges
Scan
Jump
SELECT MEMORY SCAN
(p. ??)
Not yet
programmed
ch 1 ch 2
SEL
ch 50
SEL
ch 49 ch 6
SEL SEL
MODE SELECT MEMORY
SCAN (p. ??)
Not yet programmed
ch 1 ch 2
FM
ch 50
FM
ch 49 ch 6
FM FM
49
Repeatedly scans between
two user-programmed fre-
quencies. Used for checking
for frequencies within a
specified range such as re-
peater output frequencies,
etc.
Repeatedly scans only select
memory channels within a
memory bank. This function
ch 3
can be turned ON/OFF in
SEL
[Memory SCAN] tab. Select
ch 4
channels can be set in the
ch 5
memory list screen.
SEL
Repeatedly scans only se-
lected mode channels within
a memory bank. This func-
tion can be set in [Memory
ch 3
FM
SCAN] tab of the setting
ch 4
screen.
AM
ch 5
FM
Up to 25 programmed scan ranges, memory scan, memory
select scan, memory skip scan, mode select memory scan
and auto memory write scan provide scanning versatility.
MEMORY SCAN
(p. ??)
Not yet
programmed
ch 1 ch 2 ch 3
ch 50
ch 4
SKIP
ch 49 ch 6
ch 5
MEMORY SKIP SCAN
(p. ??)
Not yet
programmed
ch 1 ch 2 ch 3
ch 50
ch 4
SKIP
ch 49 ch 6
ch 5
AUTO MEMORY WRITE
SCAN (p. ??)
Scan edge
Scan edge
Scan
Pause Pause
Program Program
ch 1 ch 2
Repeatedly scans memory
channels within a memory
bank (0–25).
Skips unwanted memory
channels that inconveniently
stop scanning. This function
can be turned ON/OFF in
[Memory SCAN] tab. Skip
channels can be set in the
memory list screen.
The frequencies that the
programmed scan stops are
automatically programmed
into a selected memory
bank.
