JANOME DESKTOP ROBOT
JR3000 Series
Operation Manual
Teaching Pendant Operation
Thank you for purchasing this Janome Robot.
Before using your robot, please read this manual thoroughly
and always make sure you use the robot correctly. In
particular, be sure to thoroughly read "For Your Safety" as it
contains important safety information.
After reading this manual, store in a safe place that can be
easily accessed at any time by the operator.
