Trigger
Trigger Sensitivity
(Edge Trigger Type)
Trigger Level Range
Trigger Level
Accuracy, typical
(Accuracy is for
signals having rise
and fall times ≥20ns)
Set Level to 50%,
typical
Note: Bandwidth reduced to 6MHz when using a 1X probe.
Coupling Sensitivity
Source
DC
CH1
CH2
AC Attenuates signals below 10Hz
HF Reject Attenuates signals above 80kHz
Same as the DC-coupled limits for frequencies above
LF Reject
150kHz; attenuates signals below 150kHz
Source Range
CH1, CH2 ±8 divisions from center of screen
Source Accuracy
0.2div × volts/div within ±4 divisions from center of
CH1 CH2
screen
Operates with input signals ≥50Hz
www.burntec.com
MS6060
MS6100
1div from DC to
10MHz;
1.5div from 10MHz
to Full
77
MS6200
1.5div from 10MHz
to 100MHz;
2div from 100MHz
to Full
