Slope Trigger: Judges trigger according to the rising or falling time (more flexible and accurate than the
Edge trigger).
Options
Slope (F1)
Source (F2)
Slope (F3)
Mode (F4)
Coupling (F2)
(menu page 2)
Vertical (F3)
(menu page 2)
When (F4)
(menu page 2)
Time (F2)
20ns to 10.0sec
(menu page 3)
Settings
Choose which slope the signal is triggered from.
CH1
Select the input source as the trigger signal.
CH2
Rising
Select which slope of the signal is triggered on.
Falling
Normal
Select the type of trigger. The Normal mode is best for
Auto
most applications.
Single
DC
AC
Selects the components of the trigger signal applied to the
Noise Reject
trigger circuitry.
HF Reject
LF Reject
V1
Adjust the vertical window by setting two trigger levels.
V2
=
≠
Select the trigger condition.
>
<
With this option highlighted, set the time span using the
multifunction control.
